Example: RGBMaker

Example 1

Making composite image of TGSS - DSS2 Red - NVSS with catalog data from Vizier and Spectral Index data from Spidx file catalog - de Gasperin, Intema & Frail, MNRAS, 474, 5008 (2018).

from rgbmaker.fetch import query
import pathlib
filepath = pathlib.Path('__file__').parent.resolve() /  "../../jupyter-checks/spidx.fits"
position='speca'
query(position=position, px=150, kind='plot', annot=0, spidx_file=filepath)

[output] :

('success',
'completed in 9.146. ',
[{'NVSS': 'value ranges from -0.0020 to 0.0356'},
{'TGSS ADR1': 'value ranges from -0.0145 to 0.0775'},
{'VLA FIRST (1.4 GHz)': 'value ranges from -0.0008 to 0.0086'},
{'Target center': '14h09m48.82860267s -03d02m33.04700421s'},
{'TGSS contour ': '[0.015 0.031 0.046 0.062]'},
{'FIRST contour ': '[0.0005 0.0025 0.0045 0.0065]'},
{'NVSS contour ': '[0.0015 0.01   0.0185 0.027 ]'},
{'S_TGSS-1': '94.2 mJy'},
{'S_TGSS_e-1': '12.1 mJy'},
{'S_TGSS-2': '100.6 mJy'},
{'S_TGSS_e-2': '12.6 mJy'},
{'S_TGSS-3': '424.0 mJy'},
{'S_TGSS_e-3': '42.6 mJy'},
{'S_NVSS-1': '9.2 mJy'},
{'S_NVSS_e-1': '1.2 mJy'},
{'S_NVSS-2': '16.9 mJy'},
{'S_NVSS_e-2': '2.1 mJy'},
{'S_NVSS-3': '32.5 mJy'},
{'S_NVSS_e-3': '1.4 mJy'},
{'S_NVSS-4': '45.0 mJy'},
{'S_NVSS_e-4': '2.0 mJy'},
{'S_NVSS-5': '60.0 mJy'},
{'S_NVSS_e-5': '2.6 mJy'},
{'S_NVSS-6': '4.3 mJy'},
{'S_NVSS_e-6': '0.4 mJy'}])

Example 2

from rgbmaker.imgplt import pl_powerlawsi
S = [424.0, 60.0]
S_e = [42.6, 2.6]

pl_powerlawsi(S,S_e)
